AUTO GATE PARKING
GROUP LEADER : Muhammad Nurakhli Bin Hubandi
PROJECT MANAGER : Nadzirah Binti Khairuddin
MEMBERS :
1) Zan Azrai Bin Mohammad Yusuf
2) Norfariza Binti Cheya
3) Noorafzan Binti Alias
4) Faiz Syahmi Bin Ithnin
5) Mohd Saiful Adli Bin Kamaruddin
INTRODUCTION
GROUP LEADER : Muhammad Nurakhli Bin Hubandi
PROJECT MANAGER : Nadzirah Binti Khairuddin
MEMBERS :
1) Zan Azrai Bin Mohammad Yusuf
2) Norfariza Binti Cheya
3) Noorafzan Binti Alias
4) Faiz Syahmi Bin Ithnin
5) Mohd Saiful Adli Bin Kamaruddin
INTRODUCTION
We using two sensor, two limit switch and motor to operate our mini project.
This mini project using a infrared type sensor to detect object that through it. Limit switch to stop motor operation and motor to do a clockwise and anticlockwise movement.
OPERATION
Firstly, sensor 1 will detect a object that through it. Motor will active and bar move anticlockwise. When bar is open, automatically the bar will touch a limit switch and motor will stop operate. When sensor 2 detect the object The bar still open. Motor will start operate again when both sensor 1 and 2 don’t detect any object through it. Motor will move clocwise and the bar will close. The bar will touch a limit switch and motor will stop operate.
IMAGE OBJECT
FLOWCHART
